Model RLC Ring Torsion Load Cell

Price range: $829.72 through $1,140.00 Inc Shipping

The RLC is a low profile, high-performance stainless-steel ring torsion type load cell.

Capacity range: 250 kg to 60 t
Low-profile, stainless-steel construction
Hermetically sealed, IP66 and IP68; IP69K is available for 250 kg, 5 t and 10 t versions

Download Data Sheet – RLC Ring Torsion Load Cell

Capacity

Accuracy / Class Code

Approval & Safety Code

Cable Length

Environmental Code

Load Cell Types

Material

Mounting

Output

Quantity	Price	Discount
1-4	$829.72	$0.00
5+	$746.75	10%

Add to wishlist

Guaranteed Safe Checkout

SKU: N/A Category: Compression

SKU	Capacity	Status	Price	Add
00RLC-500K-C3-00X	500-kg, oiml-3000-d, not-atex-fm-approved, 5-m, , compression, stainless-steel, th, standard-product	In Stock	$829.72 Inc Shipping	Add
00RLC-001T-C3-00X	1000-kg, oiml-3000-d, not-atex-fm-approved, 5-m, , compression, stainless-steel, th, standard-product	In Stock	$855.65 Inc Shipping	Add
00RLC-002T-C3-00X	2000-kg, oiml-3000-d, not-atex-fm-approved, 5-m, , compression, stainless-steel, th, standard-product	In Stock	$959.36 Inc Shipping	Add
00RLC-005T-C3-00X	1-klb-to-5-klb, oiml-3000-d, not-atex-fm-approved, 5-m, , compression, stainless-steel, th, standard-product	In Stock	$959.36 Inc Shipping	Add
00RLC-010T-C3-00X	10-klb, oiml-3000-d, not-atex-fm-approved, 5-m, , compression, stainless-steel, th, standard-product	In Stock	$1,140.00 Inc Shipping	Add

Description

The RLC is a low profile, high-performance stainless-steel ring torsion type load cell.

The fully welded construction and glass-to-metal cable entry ensure that this product can be used successfully in harsh environments found in the food, chemical and allied process industries.

This product is suitable for small and medium platform scales, hoppers and process weighing.

This product meets the stringent Weights and Measures requirements throughout Europe and USA.

Features

Capacity range: 250 kg to 60 t
Low profile, stainless steel construction
Hermetically sealed, IP66 and IP68; IP69K is available for 250 kg, 5 t and 10 t versions
Meets OIML R-60 and NTEP 6000d
Outputs are matched to ensure easy and accurate parallel connection of multiple load cells

Options

ATEX certified versions are available for use in potentially explosive atmospheres
Multi-interval and multiple-range versions are available

Certifications

Parameter	Value	Unit
Rated capacity (kg)	0.25t, 0.5t, 1t, 2t, 3.5t, 5t, 10t, 28t, 60t	kg
NTEP/oiml accuracy class	NTEP IIIL \| D3 \| C3 \| C6
Max. no. of intervals (n)	10000 \| \| 3000 \| 6000
Rated output R.O	2 (1.75 for 0.25 t, 2.05 for 10 t)	mV/V
Zero balance	1.0	±%FSO
Creep error	0.0245 \| 0.0123	±%FSO
Temp. effect on sensitivity	(0.0010) \| (0.0010) \| 0.0070 0.0045	±%FSO/F
Temp. effect on min dead load output	(0.0008) \| (0.0008) \| 0.0050 \| 0.0025	±%FSO/F
Ultimate over load	300	% of R.C
Excitation voltage	5 - 15	VDC or VAC RMS
Max. excitation voltage	30	VDC or VAC RMS
Input resistance	1110±50 (1100±50 for 0.25t and 10t) \| 1075±100 for 28t \| 1350±100 for 60t	Ω
Output resistance	1025±25 (1025±50 for 0.25t and 10t) \| 930±0.5 for 28t \| 1175±0.5 for 60t	Ω
Insulation resistance	≥5000 (20 for 28 and 60 t)	MΩ
Environmental protection	IP66 and IP68; IP69K available for 250 kg, 5t and 10t

FSO - Full Scale Output
All specifications subjects to change whithout notice.

Application

Platform scales
Belt scales
Silo hopper weighing

Capacity This load may also be available in other capacities. If your required quantity isn’t listed, please request a custom quote	1 klb to 5 klb , 10 klb , 1000 kg , 2000 kg , 500 kg
Accuracy / Class Code	OIML 3000 d OIML certified; 3000 divisions.
Approval & Safety Code	Not ATEX/FM approved No certification for ATEX or FM; cannot be used in regulated hazardous zones.
Cable Length	5 m
Environmental Code	IP66 Dust-tight and protected against powerful water jets. Often used in washdown environments. , IP68 Dust-tight and protected against continuous immersion in water under conditions specified by the manufacturer.
Load Cell Types	Compression
Material	Stainless Steel
Mounting	TH Threaded Hole – generic threaded design (could be metric or unified).
Output	Standard Product

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Revere Transducers is a trusted global leader in precision load cells and weighing solutions. Known for their exceptional accuracy, long-term stability, and robust engineering, Revere Transducers are widely used in industrial scales, process weighing, and OEM applications. Their products are designed to deliver reliable performance in the most demanding environments.
